Rho los txheem
Specifications
Qib txog tus piv ntawm lub taub hau taub Dto kav hlaub taub d yog ntawm 1.7 ~ 2.2.
Qib B: tus piv ntawm lub taub hau taub Dto kav hlaub taub d yog ntawm 1.2 ~ 1.4.
Rooj 1. qib ATrimetal Rivet Dimensionsandamp; Tolerances (hli)
Yam khoom | D(Φ) taub hau | Thickness(T) taub hau | Lub taub hau tiv tauj txheej Thickness (S1) | Kav hlaub txheej hu rau Thickness (S2) | Kav hlaub Diameterd(Φ) | Kav hlaub ntev | Voos kheej-kheej kheej kheej | Demould angleθ(o) |
Sau me me | 2.5~3.2 | 0.4~1.1 | 0.15~0.5 | 0.2~1.0 | 1.5 | 1.0~2.5 | 5~12 | 11 |
3.3~4.2 | 0.6~1.2 | 0.25~0.6 | 0.2~1.0 | 2.0 | 1.3~3.5 | 6~12 | ||
4.3~5.0 | 0.8~1.5 | 0.35~0.7 | 0.2~1.0 | 2.5 | 1.5~4.0 | 8~15 | ||
Kam rau ua ntau yam | ±0.08 | ±0.03 | ≤0.4+0.04 | ±0.04 | -0.02 | +0.15 | ±2 | ±2 |
2 cov lus. Qib B Trimetal Rivet Dimensionsandamp; Tolerances (hli)
Yam khoom | D(Φ) taub hau | Thickness(T) taub hau | Lub taub hau tiv tauj txheej Thickness (S1) | Kav hlaub txheej hu rau Thickness (S2) | Kav hlaub Diameterd(Φ) | Kav hlaub ntev | Voos kheej-kheej kheej kheej | Demould angleθ(o) |
Sau me me | 2.5~3.5 | 0.4~0.9 | 0.2~0.35 | 0.3~0.5 | 1.8~2.2 | 0.8~1.5 | 6~12 | 13 |
3.0~4.0 | 0.6~1.1 | 0.25~0.5 | 0.3~0.6 | 2.4~2.7 | 0.9~1.8 | 8~15 | ||
4.0~4.5 | 0.7~1.2 | 0.3~0.55 | 0.3~0.6 | 2.9~3.2 | 1.0~2.0 | 10~20 | ||
4.5~5.5 | 0.8~1.5 | 0.3~0.6 | 0.4~0.7 | 3.5~4.5 | 1.5~2.5 | 12~30 | ||
5.5~6.5 | 0.9~1.5 | 0.3~0.6 | 0.4~0.7 | 4.5~5.5 | 1.5~3.0 | 15~40 | ||
6.5~7.5 | 1.0~2.0 | 0.4~0.7 | 0.5~0.8 | 5.5~6.5 | 2.0~4.5 | 20~60 | ||
Kam rau ua ntau yam | ±0.08 | ±0.03 | ≤0.4+0.04 | ±0.04 | -0.02 | +0.15 | ±2 | ±2 |
Ntawv loj
Trimetal rivets yog siv los ua doublesidescontacts, mas siv hauv relays, micro keyboards, bottomswitches thiabcontactors.
Khoom tseem ceeb
AgCu/Cu, Ag/Cu, AgNi/Cu, AgSnO2In2O3/Cu, AgSnO2/Cu, AgCdO/Cu, AgCuO/Cu, AgZnO/Cu.
Khoom Diam duab yeeb yam
Aokai fais yog koj qhov chaw zoo rau tus siab zoo nyiaj dag trimetal hu rau rivets nrog CE muab ntawv pov thawj. Peb tau muaj ib yam ntawm cov coob xws manufacturers thiab lwm tus neeg nyob hauv Suav teb vim hais tias peb lub tsev lag luam rau xyoo 2008. Txais tos hu peb koom xwm rau cov khoom siv.
Cim npe nrov: nrig txog tooj dag nyiaj trimetal rau rivets, Suav teb, lwm tus neeg, lub hoobkas, CE manufacturers
